Thông số sản phẩm Switch chia mạng TP-Link T1700G-28TQ – 24 port
– Switch TP-Link T1700G-28TQ 24 cổng RJ45 10/100/1000Mbps + 4 slot 10G SFP.
– QoS L2/ L3/ L4 và ICMP Snooping tối ưu hóa cho các ứng dụng audio và video.
– Với SNMP, RMON, WEB/ CLI, mang lại các tính năng quản trị đa dạng.
– Nguồn điện: 100-240VAC, 50/60Hz
– Công suất tiêu thụ: Tối đa 21.8W
– Địa chỉ MAC: 16K
– Bộ nhớ gói dữ liệu đệm: 1.5MB
– 10G SFP+ ports for stacking and/or uplink, applications for congestion relief, smooth data delivery, providing support for high-bandwidth
– True physical stacking supports up to 6 units and 40Gbps bi-directional bandwidth for high scalability and efcient redundancy
– Advanced security features include IP-MAC-Port Binding, ACL, DoS Defend, Port Security, Storm
– Control, DHCP Snooping, 802.1X, and Radius Authentication
– IPv6 support provides dual IPv4/IPv6 stacking, MLD snooping, and IPv6 neighbor discovery
Đặc tính kỹ thuật Switch TP-LINK T1700G-28TQ
| Standards and Protocols | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ae, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p |
| Interfaces | 24 10/100/1000Mbps RJ45 Ports |
| 4 fixed 10G SFP+ Slots | |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
| 100BASE-TX/1000Base-T: UTP cat 5, 5e hoặc above cable (maximum 100m) | |
| 1000BASE-X: MMF, SMF | |
| 10GBASE-LR | |
| 10GBASE-SR | |
| Installable SFP + Transceivers and Direct Attach Copper (DAC) Cables | TXM431-SR |
| TXM432-LR | |
| TXC432-CU1M | |
| TXC432-CU3M | |
| Max Number of Stacking Ports Installable | 2 SFP+ |
| Stacking Speed (Per Port) | 20Gbps (Full-Duplex) |
| Max Number of Units Per Stack | 6 |
| Switching Capacity | Up to 128Gbps for a standalone switch |
| Packet Forwarding Rate | Up to 95.2Mpps for a standalone switch |
| MAC Address Table | 16K |
| Packet Buffer Memory | 1.5MB |
| Number of IP Interfaces | 16 |
| Number of Static Routes | 32 IPv4 |
| Jumbo Frame | 9KB |
| Power Supply | 100-240VAC, 50/60Hz |
| Maximum Power Consumption | 21.8W (220V/50W) |
| FAN Quantity | Fanless |
| Certication | CE, FCC |
| Dimensions | 440 x 180 x 44 mm |
| Weight | 2.8kg |
